chromaPIXA 2k
Trilinear CCD color line sensor Color measurement for every pixel
chromaPIXA 2k
The chromaPIXA line scan camera has 3 x 2048 pixel and enables stable inline color measurement in a wide variety of extended color spaces, greatly simplifying downstream color processing. The chromaPIXA’s output in CIE-L*a*b* format allows for the superior determination of color differences to the perception of the human eye. The camera is calibrated by using the intuitive chromaCalc software and is compatible with all standard color charts.
Key Features
- Trilinear CCD color line sensor
- 2,048 x 3 to 7,300 x 3 pixels
- Pixel size 10 x 10 µm
- Interface Camera Link Base/Medium/Full
- Line rates up to 92.7 kHz
- Conversion to sRGB, eciRGB, AdobeRGB, CIE-L*a*b* or CIE-XYZ in real time
- Calibration with all common ColorChecker
- Color measurement for every pixel
Applications
- Print inspection
- Sorting
- Inline color control
- Inline color measurement
Specification
| Technical Specifications | |
|---|---|
| Sensor | Trilinear CCD color line scan sensor |
| Active pixel size | 10 μm * 10 μm |
| Max. Line rate | 2048 x 3 Pixel with up to 90.7 kHz |
| Farbausgaberaum | sRGB, eciRGB, AdobeRGB, Cie-L*a*b*, CIE-XYZ |
| Data format | 3 x 8/10 bit coloror with internal 3 x 14 Bit A/D converter |
| Video-Ouput | Camera Link @ 85MHz Full (80/64 Bit), Medium, Base |
| Trigger mode | Free run / external trigger Line trigger, Frame trigger |
| Software | chromaCalc software generate calibration data to calculate color output |
| Light source | Recommend Chromasens Corona II D50 for best performance |
| Interfaces | Camera Link Full, Medium, Base Power supply (Hirose) External I/O (15pin D-Sub) RS232 |
| Certifications | CE, RoHS |
| Power supply | 24 V DC +/- 10 %, max. 19 W RS232 |
| Operating temperature | 0°C to 60°C, 32°F to 140°F (housing temp.) |
| Dimensions | L = 102 mm, H =100 mm, D = 77 mm |
| Lens mount / adapters | F-Mount, C-Mount, M39x1/26″, M42x1, M72x0.75 |
